DC DC Converter for PV/Renewable Energy DIN Rail 12VDC 16.7A DDRH-240-12
677.00 ر.س
DC DC Converter
12VDC 16.7A
Available on backorder
Description
DC DC Converter Din Rail for PV/Renewable Energy
Brand:Mean Well
Model:DDRH-240-12
Output:12VDC 16.7A
Multiple installation available(PCB mounted, screw terminal and DIN rail type)
150~1500Vdc 10:1 ultra-wide input range
Potted, provides dust and moisture protection
Ultra-wide temperature range: -40oC?+80oC
Protections: Short circuit / Overload / Over voltage / DC input under voltage / DC input reverse polarity
Datasheet:
Specifications
| Shipping Weight | 1.2 kg |
|---|---|
| Dimensions | 8.55 × 12.52 × 12.92 cm |
| Brand |
Mean Well |
| Input Voltage (VDC) |
250~1500 |
| IP Rating |
not assigned |
| Model |
DDRH-240-12 |
| Output Power (W) |
240 |
| Output |
12 |
| Product Dimension (LxWxH) (mm) |
85.5×125.2×129.2 |
| Product Weight (kg) |
0.96 |
| ROHS |
ROHS |
| Safety |
CE ,EAC |
| Series |
DDRH |
| Shape |
DIN Rail |
| Technology |
DC/DC |
